Appendix A 7
Specifications
Models A2004 to A2075
Inverter model 3G3IV-
-
200 to 230 V
A2004 A2007 A2015 A2022 A2037 A2055 A2075
Max. applicable motor output Hp (kW) (See Note 1) 0.5
(0.4)
1
(0.75)
2
(1.5)
3
(2.2)
5
(3.7)
7.5
(5.5)
10
(7.5)
Output characteristics Inverter capacity kVA 1.4 2.1 2.7 4.1 6.9 10.3 13.7
Rated output current A 3.2 4.8 6.4 9.6 16 24 32
Max. continuous output
current (See Note 2) A
3.6 5.4 7.2 10.8 18 27 36
Max. output voltage 3-phase, 200/208/220/230 V (Proportional to input voltage)
Rated output frequency 50, 60, 72, 90, 120, 180 Hz (up to 400 Hz available)
Power supply Rated input voltage and
frequency
3-Phase: 200/208/220 V, 50 Hz, 200/208/220/230 V, 60 Hz
Allowable voltage fluctuation ±10%
Allowable frequency
fluctuation
±5%
Control characteristics Control method Sine wave PWM
Frequency control range 0.1 to 400 Hz
Frequency accuracy Digital command: 0.01%, +14° to 104°F, -- 10 ° to 40°C
Analog command: 0.1%, 77°
±
18°F, 25°
±
10°C
Frequency resolution Digital operator reference: 0.1 Hz
Analog reference: 0.06 Hz/60 Hz
Output frequency resolution 0.01 Hz (1/30000)
Overload capacity 150% rated output current for one minute
Frequency setting signal
0to10VDC(20kΩ),4to20mA(250Ω)0
±
10 V
(OPTIONAL)
Accel/Decel time 0.1 to 6000 sec. (Accel/Decel time setting independently)
Braking torque Approx. 20%
No. of V-f patterns
(Total of 16)
4: For general purpose
4: For high starting torque:
1: For adjustable pattern
4: For fans and pumps
3: For machine tools.
Protective functions Motor overload protection Electric thermal overload relay
Instantaneous overcurrent Motor coasts to a stop at approx. 200% rated current.
Fuse blown protection Motor coasts to a stop by blown-fuse.
Overload Motor coasts to a stop for 1 minute at 150% rated output
current.
Overvoltage Motor coasts to a stop if converter output voltage exceeds
400 V.
Undervoltage Motor coasts to a stop if converter output voltage drops to
210 V or below (See Note 3).
Momentary power loss Immediately stop by 15 ms and above momentary power loss.
(Continuous system operation during power loss less than 2
sec is equipped as standard. See Note 2.) Setting made
before shipment.
Fin overheat Thermostat
