Omron SYSDRIVE 3G3IV User Manual

Appendix C
$
400 HP (300 kW) (Model 3G3IV-B430K-E) Open Chassis Type
Approx. Weight: 420 kg
298
32
855
410 min.
455
25
347
1550
1600
113
150 max.
966 max.
960
440
310
342
70
58.5
1094
575
55
70
106
25
Six, M12 dia. mtg. holes
Digital
Operator
Control circuit terminal M3.5
Front cover
Cooling fan
AIR
Grounding
terminal M8
Control circuit terminal M4
Wiring
space
Main circuit
terminal M16
Dimensions
H1 H
W1
W
D
4-d dia mtg. holes
The dimensions to the above shows Model 3G3IV-A2075-E.
Remove the upper and lower covers of the enclosed type units when it is applied as the open chassis type.
