6
(1)
(1)
(2)
Terminal Position
The main circuit and control circuit terminal blocks are shown
below. Terminal numbers are usually shown on the terminal num-
ber nameplate, but the terminal numbers are printed on the printed
board on some Inverters.
Main circuit
terminal block
Control circuit
terminal block
CHARGE indicator
Grounding terminal
Fault signal
output terminal
(FLT– A, B, C)
Wiring Section 1-4
