2
1-1 Part Names of the 3G3XV
The following diagram shows the main components of the SYS-
DRIVE 3G3XV. The terminal block cover has been removed to
expose the terminal blocks. Refer to
1-4-1 Terminal Blocks
for
details on removing the terminal block cover.
Digital Operator
(Model 3G3XV-PJVOP110)
Set the operating constants with the
Digital Operator. (3G3XV-series only)
Control circuit terminal block
CHARGE indicator
Do not touch the main circuit ter-
minals when this indicator is lit.
Main circuit terminal block
1-2 Receiving
This SYSDRIVE 3G3XV has been put through demanding tests at
the factory before shipment.
After unpacking, check for the following.
Verify the part numbers with the purchase order sheet and/or
packing slip.
Transit damage.
If any part of 3G3XV is damaged or lost, immediately notify the
shipper.
Nameplate Data
Inverter Model
Input specifications
Output specifications
Receiving Section 1-2
