Omron SYSDRIVE 3G3XV-EV2 Series

44
Function See
Page
User
set
values
Initial
setting
DescriptionNameNo.
Speed search
control
54 Speed
search
deactivation
current level
Setting unit: 1%, setting range: 0 to 200 150% 61
55 Min. base-
block time
Setting unit: 0.1 s, setting range: 0.0 to
5.0
0.5 s
56 V/F during
speed
search
Setting unit: 0.1 s, setting range: 0.0 to
100.0
100%
Slip compensa-
tion speed con-
trol
57 Slip com-
pensation
function
Setting unit: 0.1%, setting range: 0.0 to
9.9
(100% = Max. Frequency)
0.0% 64
58 Motor no-
load current
Setting unit: 0%, setting range: 0 to 99
(100% = Motor reated current n%19)
30%
59 Torque com-
pensation fil-
ter time
delay
Setting unit: 0.1%, setting range: 0.1 to
25.5
2 s
Factory setting 60
to
66
--- Do not set. --- --- ---
Inverter over-
load protection
67 OL2 contin-
uous opera-
tion selec-
tion
0: Continuous operation at 103% of rated
current.
1:Continuous operation at 112% of rated
current.
0001 65
Factory setting 68,
69
--- Do not set. --- --- ---
Note When setting the third function, set n%0 to 3.
2-8 Description of Functions and Constants
2-8-1 Password Setting
Constant No. 00 is used both to limit read/write access to groups of
constants and to clear the fault history or initialize constants. The
following tables show the possible values for constant No. 00 and
their corresponding functions.
Constant no. 00 value Function
0 (write-protect setting) Read access: Nos. 00 to 19 only
Write access: No. 00 only
1 (initial setting) Read access: Nos. 00 to 19 only
Write access: Nos. 00 to 19 only
2 Read access: Nos. 00 to 29 only
Write access: Nos. 00 to 29 only
3 Read access: Nos. 00 to 59
Write access: Nos. 00 to 59
6 Clears the fault history.
Description of Functions and Constants Section 2-8
