3
Inverter Model Numbers
Country
EV2: European countries
(E: Old model)
None:Japan
Max. Applicable Motor Capacity
001: 0.1 kW
002: 0.2 kW
004: 0.4 kW
..
..
..
037: 3.7 kW
Voltage Class
2: 3-phase, 200 V
4: 3-phase, 400 V
B: Single-phase, 200 V
Protective Structure
A: Enclosed wall mounting
P: Optional structure
3G3XV-A4002-EV2
3G3XV-series
WARNING
1, 2, 3...
1. After turning off the main circuit power supply, do not touch cir-
cuit components until the “CHARGE” indicator is extinguished.
The capacitors are still charged and can be quite dangerous.
2. Do not change the wiring while power is applied to the circuit.
3. Do not check signals during operation.
4. Be sure to ground 3G3XV using the ground terminal G (E).
5. Never connect main circuit output terminals, T1 (U), T2 (V), T3
(W), to AC main circuit supply.
Caution
1, 2, 3...
1. All the constants of 3G3XV have been adjusted at the factory.
Do not change their settings unnecessarily.
2. Do not perform withstand voltage test on any part of the 3G3XV
Unit. This electronic equipment uses semi-conductors and is
vulnerable to high voltage.
1-3 Installation
1-3-1 Location
Location of the equipment is important to achieve proper perfor-
mance and normal operating life.
The 3G3XV Units should be installed in areas where the following
conditions exist.
Ambient temperature:
–10° to 40°C, 14° to 104°F (with top cover on)
–10° to 45°C, 14° to 113°F (with top cover off)
Protected from rain or moisture.
Installation Section 1-3
