3-30
3-7 Parameter List
3
Operation
Acceleration/Deceleration
A150
EL-S-curve ratio 1
during acceleration
0. to 50. 25. No No %
4-39
A151
EL-S-curve ratio 2
during acceleration
0. to 50. 25. No No %
A152
EL-S-curve ratio 1
during deceleration
0. to 50. 25. No No %
A153
EL-S-curve ratio 2
during deceleration
0. to 50. 25. No No %
Momentary power interruption/Trip restart
b001 Retry selection
00: Alarm
01: 0 Hz start
02: Frequency matching start
03: Trip after frequency matching
deceleration stop
04: Frequency pull-in restart
00 No Yes 
4-42
b002
Allowable
momentary power
interruption time
0.3 to 25.0 1.0 No Yes s
b003 Retry wait time 0.3 to 100.0 1.0 No Yes s 4-85
b004
Momentary power
interruption/
undervoltage trip
during stop selection
00: Disabled
01: Enabled
02: Disabled during stop and deceleration
stop
00 No Yes 
4-42
b005
Momentary power
interruption retry time
selection
00: 16 times
01: No limit
00 No Yes 
b006
Input phase loss
protection selection
00: Disabled
01: Enabled
00 No Yes  4-46
b007
Frequency matching
lower limit frequency
setting
0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
4-42
4-68
4-85
b008 Trip retry selection
00: Trip
01: 0 Hz start
02: Frequency matching start
03: Trip after frequency matching
deceleration stop
04: Frequency pull-in restart
00 No Yes 
4-42
b009
Undervoltage retry
time selection
00: 16 times
01: No limit
00 No Yes 
4-43
b010
Overvoltage/
overcurrent retry time
selection
1 to 3 3 No Yes Time
b011 Trip retry wait time 0.3 to 100.0 1.0 No Yes s
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
