3-29
3-7 Parameter List
3
Operation
External frequency adjustment
A101 FI start frequency
0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
4-14
A102 FI end frequency 0.00 No Yes Hz
A103 FI start ratio 0. to FI end ratio 20. No Yes %
A104 FI end ratio FI start ratio to 100. 100. No Yes %
A105 FI start selection
00: Use FI start frequency [A101]
01: 0 Hz
00 No Yes 
A111 FE start frequency -400. to -100.
-99.9 to 0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
4-15
A112 FE end frequency 0.00 No Yes Hz
A113 FE start ratio -100. to FE end ratio -100. No Yes %
A114 FE end ratio FE start ratio to 100. 100. No Yes %
Acceleration/Deceleration
A131
Acceleration curve
parameter
01 (small curve) to 10 (large curve)
02 No Yes 
4-39
A132
Deceleration curve
parameter
02 No Yes 
Operation frequency
A141
Operation frequency
input A setting
00: Digital Operator (F001)
01: Digital Operator (FREQ adjuster)
(Enabled when 3G3AX-OP01 is used.)
02: Input FV
03: Input FI
04: RS485 communication
05: Option 1
06: Option 2
07: Pulse train frequency
02 No Yes 
4-41
A142
Operation frequency
input B setting
03 No Yes 
A143 Operator selection
00: Addition (A + B)
01: Subtraction (A - B)
02: Multiplication (A × B)
00 No Yes 
A145
Frequency addition
amount
0.00 to 99.99
100.0 to 400.0
0.00 No Yes Hz
4-41
A146
Frequency addition
direction
00: Add A145 value to output frequency
01: Subtract A145 value from output
frequency
00 No Yes 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
