Omron Sysdrive RX Series - Page 85

3-36
3-7 Parameter List
3
Operation
Others
b060
Window comparator
FV upper limit level
Set an upper limit level.
Setting range: 0 to 100
Lower limit: Lower limit level + Hysteresis
width × 2
100. Yes Yes %
4-63
b061
Window comparator
FV lower limit level
Set a lower limit level.
Setting range: 0 to 100
Upper limit: Upper limit level - Hysteresis
width × 2
0. Yes Yes %
b062
Window comparator
FV hysteresis width
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0 to 10
Upper limit: (Upper limit level - Lower limit
level) × 2
0. Yes Yes %
b063
Window comparator
FI upper limit level
Set an upper limit level.
Setting range: 0 to 100
Lower limit: Lower limit level + Hysteresis
width × 2
100. Yes Yes %
b064
Window comparator
FI lower limit level
Set a lower limit level.
Setting range: 0 to 100
Upper limit: Upper limit level - Hysteresis
width × 2
0. Yes Yes %
b065
Window comparator
FI hysteresis width
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0 to 10
Upper limit: (Upper limit level - Lower limit
level) × 2
0. Yes Yes %
b066
Window comparator
FE upper limit level
Set an upper limit level.
Setting range: -100 to 100
Lower limit: Lower limit level + Hysteresis
width × 2
100. Yes Yes %
b067
Window comparator
FE lower limit level
Set a lower limit level.
Setting range: -100 to 100
Upper limit: Upper limit level - Hysteresis
width × 2
-100. Yes Yes %
4-63
b068
Window comparator
FE hysteresis width
Set a hysteresis width for the upper and
lower limit levels.
Setting range: 0 to 10
Upper limit: (Upper limit level - Lower limit
level) × 2
0. Yes Yes %
b070
Analog operation
level at FV
disconnection
0. to 100./no (ignored) no No Yes 
b071
Analog operation
level at FI
disconnection
0. to 100./no (ignored) no No Yes 
b072
Analog operation
level at FE
disconnection
-100. to 100./no (ignored) no No Yes 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
