Omron SYSMAC CP2E-E D Series User Manual

7 PLC Setup
7-12
CP2E CPU Unit Software User’s Manual(W614)
22-8 Modbus RTU Slave Settings
2-8-1 Baud 9,600 bps
1,200 bps
When power is turned ON
2,400 bps
4,800 bps
9,600 bps
19,200 bps
38,400 bps
57,600 bps
115,200 bps
2-8-2 Format
(data length, stop bits,
parity)
8 bits, 1 bit, even
8 bits, 1 bit, even
When power is turned ON
8 bits, 2 bits, no parity
8 bits, 1 bit, odd
2-8-3 Modbus Slave Address 1
0 (Slave Address 1)
When power is turned ON
1
:
247
Name Default Possible settings
When setting is read by
CPU Unit
