8 Overview of Built-in Functions and Allocations

CP2E CPU Unit Software User’s Manual(W614)

8-3 Terminal Allocations for Built-in Functions

8-3-2 Selecting Functions in the PLC Setup

• The input and output terminals used by the origin search function can be enabled by selecting the

Use define origin operation Check Box on a Pulse Output Tab Page.

Select the Use define origin

operation Check Box.
