12 Pulse Outputs
CP2E CPU Unit Software User’s Manual(W614)
12-1 Overview
12
12-1-2 Flow of Operation
Origin Searches
Use the following input and output terminals for origin searches.
Input Terminals
• N20/30/40/60 or S30/40/60 CPU Units
Note 1 Only supported by N30/40/60 CPU Units.
2 Only supported by N20/30/40/60 CPU Units.
• N14 CPU Units
Input terminal block Setting in PLC Setup
Other functions that cannot be used at the same time
Terminal
block
label
Terminal
number
Enable origin searches
for pulse outputs 0 to 3
Normal
inputs
Interrupt
inputs
Quick-response
inputs
High-speed
counter setting
Increment
pulse input
CIO 0 06 Pulse 0, Origin input signal Normal
input 6
Interrupt
input 6
Quick-response
input 6
High-speed
counter 5
07 Pulse 1, Origin input signal Normal
input 7
Interrupt
input 7
Quick-response
input 7
−
08 Pulse 2, Origin input signal
(Note 1)
Normal
input 8
Interrupt
input 8
(Note 2)
Quick-response
input 8 (Note 2)
−
09 Pulse 3, Origin input signal
(Note 1)
Normal
input 9
Interrupt
input 9
(Note 2)
Quick-response
input 9 (Note 2)
−
10 Pulse 0, Origin proximity
input signal
Normal
input 10
−− −
11 Pulse 1, Origin proximity
input signal
Normal
input 11
−− −
CIO 1 00 Pulse 2, Origin proximity
input signal (Note 1)
Normal
input 12
−− −
01 Pulse 3, Origin proximity
input signal (Note 1)
Normal
input 13
−− −
Input terminal block Setting in PLC Setup
Other functions that cannot be used at the same time
Terminal
block
label
Terminal
number
Enable origin searches
for pulse outputs 0 and 1
Normal
inputs
Interrupt
inputs
Quick-response
inputs
High-speed
counter setting
Increment
pulse input
CIO 0 03 Pulse 0, Origin proximity
input signal
Normal
input 3
Interrupt
input 3
Quick-response
input 3
−
::
05 Pulse 1, Origin proximity
input signal
Normal
input 5
Interrupt
input 5
Quick-response
input 5
High-speed
counter 4
06 Pulse 2, Origin input signal Normal
input 6
Interrupt
input 6
Quick-response
input 6
High-speed
counter 5
07 Pulse 3, Origin input signal Normal
input 7
Interrupt
input 7
Quick-response
input 7
−
