Omron SYSMAC CP2E-E D Series User Manual

Appendices
A-8
CP2E CPU Unit Software User’s Manual(W614)
ACCUMULA-
TIVE TIMER
TTIM
(BCD)
--- TTIM(087)/TTIMX(555) operates an incrementing timer with units
of 0.1-s. The setting range for the set value (SV) is 0 to 999.9 s for
TTIM(BCD) and 0 to 6,553.5 s for TTIMX(Binary).
TTIMX
(Binary)
---
LONG TIMER TIML
(BCD)
--- TIML(542)/TIMLX(553) operates a decrementing timer with units
of 0.1-s that can time up to approx. 115 days for TIML(BCD) and
49,710 days for TIMLX(Binary).
TIMLX
(Binary)
---
COUNTER CNT
(BCD)
--- CNT/CNTX(546) operates a decrementing counter. The setting
range for the set value (SV) is 0 to 9,999 for CNT(BCD) and 0 to
65,535 for CNTX(Binary).
CNTX
(Binary)
---
Instruction Mnemonic Variations Symbol/Operand Function
TTIM(087)
N
S
N: Timer number
S: Set value
Reset
input
Timer
input
Timer input
Timer PV
SV
Reset input
PV
maintained.
Timing
resumes.
Completion
Flag
ON
OFF
0
ON
OFF
ON
OFF
TTIMX(555)
N
S
N: Timer number
S: Set value
Reset
input
Timer
input
TIML(542)
D1
D2
S
D1: Completion Flag
D2: PV word
S: SV word
Timer input
Timer P
V
SV
Completion Flag
(Bit 00 of D1)
ON
OFF
0
ON
OFF
TIMLX(553)
D1
D2
S
D1: Completion Flag
D2: PV word
S: SV word
CNT
N
S
N: Counter number
S: Set value
Reset
input
Count
input
SV
Count input
Counter PV
Completion
Flag
Reset input
ON
OFF
ON
OFF
0
ON
OFF
CNTX(546)
N
S
Count
input
Reset
input
N: Counter number
S: Set value
