A-2 Auxiliary Area Allocations by Address
App
A-2-1 Read-only Words
A45 14 Ethernet Link Status
Flag (N14/20 Ethernet
port, N30/40/60
Ethernet PORT1A)
Ethernet port of N14/20 CPU unit and
port A of N30/40/60 CPU unit will be
ON when the Ethernet link is
established.
ON: Ethernet link is
established
OFF: Ethernet link is
terminated
--- Cleared Refreshed
when the
Ethernet link
status is
changed.
15 Ethernet Link Status
Flag (N30/40/60
Ethernet PORT1B)
Port B of N30/40/60 CPU unit will be
ON when the Ethernet link is
established.
A46 02 IP Address Setting
Erro Flag
ON when the IP address meets the
following conditions:
• All bits of the host ID are 0 or 1
• All bits of the net ID are 0 or 1
• All bits of the subnet ID are 1
• IP address starts with 127 (0x7F)
ON: Error
OFF: Normal
--- Cleared Refreshed
when error
occurs
03 IP Address Table Error
Flag
ON when the IP address table is
abnormal.
ON: Error
OFF: Normal
--- Cleared
04 IP Router Table Error
Flag
ON when the IP router table is
abnormal.
ON: Error
OFF: Normal
--- Cleared
05 DNS Server Error Flag ON when DNS server meets the
following conditions:
• The IP address of the server is
invalid
• Time-out occurs in server communi-
cation
ON: Error
OFF: Normal
--- Cleared
06 Routing Table Error
Flag
ON when the routing table setting is
abnormal.
ON: Error
OFF: Normal
--- Cleared
11 SNTP Server Error
Flag
ON when SNTP server meets the
following conditions:
• The IP address of the server or the
host name is invalid
• Time-out occurs in servecr commu-
nication
ON: Error
OFF: Normal
--- Cleared
14 Address Disagreement
Flag
ON when meets the following
conditions:
• IP address conversion method is set
to Automatic
• Host ID of your IP address and the
FINS node address do not match
ON: Disagree
OFF: Agree
---
Cle
ared
A47 00 FINS/TCP Connection
Establish Flag (No.1)
ON when FINS/TCP connection is
established.
ON: Connection
Established
OFF: Connection
Disconnected
--- Cleared When
connection
state changes
01 FINS/TCP Connection
Establish Flag (No.2)
02 FINS/TCP Connection
Establish Flag (No.3)
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
