A-2 Auxiliary Area Allocations by Address
App
A-2-1 Read-only Words
A351 to
A354
Calendar/Clock Area These words contain the CPU Unit’s
internal clock data in BCD. The clock
can be set from the CX-Programmer,
with the DATE instruction, or with a
FINS command (CLOCK WRITE,
0702).
A351.00 to A351.07:
Seconds (00 to 59)(BCD)
A351.08 to A351.15:
Minutes (00 to 59)(BCD)
A352.00 to A352.07:
Hours (00 to 23)(BCD)
A352.08 to A352.15:
Day of the month (01 to 31)(BCD)
A353.00 to A353.07:
Month (01 to 12)(BCD)
A353.08 to A353.15:
Year (00 to 99)(BCD)
A354.00 to A354.07:
Day of the week (00 to 06)(BCD)
00: Sunday
01: Monday
02: Tuesday
03: Wednesday
04: Thursday
05: Friday
06: Saturday
Note In an Eîš…îš…-type CPU Unit or
when time alignment cannot be
executed with an N/Sîš…îš…-type
CPU Unit, the data will be for
1:01.01 on Sunday January 1,
2001.
Retained Retained Written every
cycle
A360
to A391
01 to
15
Executed FAL Number
Flags
The flag corresponding to the specified
FAL number will be turned ON when
FAL is executed. Bits A360.01 to
A391.15 correspond to FAL numbers
001 to 511.
Note The flag will be turned OFF when
the error is cleared.
ON: That FAL
executed
O
F
F: That FAL not
executed
Retained Cleared Refreshed
when error
occurs.
A402.15
Address
Name Function Settings
Status
after
mode
change
Status at
startup
Write
timing
Related
flags,
settings
Words Bits
