Appendices
A-108
CP2E CPU Unit Software User’s Manual(W614)
Note Do not access areas reserved for the system.
Memory Map
Classification
PLC memory address
(hex)
User addresses Area
I/O memory
areas
0 to 0174F --- Reserved for system
01750 to 0176F T00 to T31 Timer Completion Flags
01770 to 0178F C00 to C31 Counter Completion Flags
01790 to 017BF --- Reserved for system
017C0 to 0197F A0 to A447 Read-only Auxiliary Area
01980 to 01B7F A448 to A959 Read/Write Auxiliary Area
01B80 to 01CA1 CIO 0 to 289 CIO Area
01CA2 to 01CBF --- Reserved for system
01CC0 to 01D3F H0 to H127 Holding Area
01D40 to 022BF --- Reserved for system
022C0 to 0233F W0 to W127 Work Area
02340 to 0253F T000 to T511 Timer PVs
02540 to 0273F C000 to C511 Counter PVs
E-type CPU Unit:
02740 to 0373F
S-type CPU Unit:
02740 to 0473F
N-type CPU Unit:
02740 to 0673F
E-type CPU Unit:
D0 to D4095
S-type CPU Unit:
D0 to D8191
N-type CPU Unit:
D0 to D16383
DM Area
E-type CPU Unit:
03740 to 0673F
S-type CPU Unit:
04740 to 0673F
--- Reserved for system
