Appendix C
Specifications and Ratings
General Ratings and Characteristics
Ratings
Supply voltage 24 VDC
Operating voltage range 20.4 to 26.4 VDC (24
+15%
/
–15%
VDC)
Power consumption 7.2 W max. (24 V, 0.3 A)
Insulation resistance 50 MΩ min. (at 500 VDC) between: Power terminals and case
I/O terminals and case
Power terminals and I/O terminals
Dielectric strength 1,000 VAC 50/60 Hz for 1 minute.
Leakage current: 10 mA max. for each of the above combinations.
Noise immunity 1,500 Vp-p, pulse width: 100 ns to 1 µs, rise time: 1 ns (common mode noise)
600 Vp-p (normal mode noise)
Vibration Mechanical
durability
10 to 150 Hz, 0.3 mm double amplitude for 32 minutes in X, Y, and Z directions.
Malfunction
durability
10 to 150 Hz, 0.2 mm double amplitude for 32 minutes in X, Y, and Z directions.
Shock 20 G, three times in X, Y, and Z directions.
Operating temperature –10° to 55°C
Operating humidity 35% to 85% RH (without condensation)
Atmosphere Must be free from corrosive gas.
Storage temperature –25° to 65°C
Protection Class Class I (with protective conductor terminal)
Protection rating IEC60529: IP30 (panel mounting)
Approved standards EN50081-2 (see note)
EN50082-2 (see note)
FCC Part 15 Subpart B
Pollution degree 2
Weight 360 g
Note For V600-CD1D-V3.
Characteristics
Self-diagnosis function CPU error, memory error, power failure, communications error check
