I/O Specifications
External I/O Specifications
Input Specifications (RESET, TRIG, IN1, IN2)
Input voltage 24 VDC
+10%
/
–15%
(including ripple)
Input impedance 2.2 kΩ
Input current 10 mA at 24 VDC (typical)
ON voltage 19 V min.
OFF voltage 5 V max.
Input response time 70 ms max.
Output Specifications (RUN, CMPL, OUT1, OUT2)
Max. switching
capacity
24 VDC
+10%
/
–15%
(including ripple), 100 mA
Leakage current 100 µA max
Residual voltage 2.0 V max.
Note 1. When the RESET input is ON, the CPU stops and the STOP indicator light.
2. If the terminals are short-circuited without load, the internal transistor may be damaged.
