Section 3 Switch Settings
Section 3
Preparing Communications
■ Setting the Mode Switch
■ Setting the Terminating Resistance
When more than one ID Controller is connected in series to a single host device, the terminating resis-
tance must be turned ON at the nodes (ID Controller or host device) on both ends of the main cable
and turned OFF at the rest of the nodes. Operation will not be stable if the terminating resistance is not
set correctly.
The terminating resistance switch connects and disconnects the built-in terminating resistance.
SW5 Description
OFF RUN mode
ON MAINTENANCE mode
SW6 Description
OFF Terminating resistance not connected.
ON Terminating resistance connected.

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
