CIDRW System
User’s Manual
SECTION 6
Characteristic Data depending on Conditions of Use
SECTION 6
Appendix
111
■ Vertical Mounting (RI-TRP-DR2B)
• READ
•WRITE
0−20
0
20
40
60
80
100
120
140
−40−60−80−100−120−140−160−180 18016014012010080604020
35 mm
Communications Areas (READ)
Distance in Y direction (mm)
Distance in Z direction (mm)
Measurement point
0−20
0
20
40
60
80
100
120
140
−40−60−80−100−120−140−160−180 18016014012010080604020
Communications Areas (WRITE)
Distance in Y direction (mm)
Distance in Z direction (mm)
35 mm
Measurement point
