112
SECTION 6
Characteristic Data depending on Conditions of Use
CIDRW System
User’s Manual
SECTION 6
Appendix
■ Coaxial Mounting (RI-TRP-WR2B)
• READ
•WRITE
0
0
−50
30
50
60
90
120
150
180
−100 100−150 150−200 200
Communications Areas (READ)
Distance in Y direction (mm)
Distance in X direction (mm)
Measurement
point
0
0
−50
30
50
60
90
120
150
180
−100 100−150 150−200 200
Communications Areas (WRITE)
Distance in Y direction (mm)
Distance in X direction (mm)
Measurement
point
