Dirnensions/Clearances (continued)
Models
Valve Lifter To
Block Clearance
Valve Seat
Diameter (Intake)
Valve Seat
Diameter (Exhaust)
6.5 NHEAND 6.3 NHEL
0.001 5-0.0030
(0.038-0.076
mm)
(39.853-39.878 m m)
1.5690-1 S700
1.2550-1.2560
- (31.877-31.902 rnm)
Valve Seat Bore
Diameter (Intake)
1.5645-1 S655
(39.738-39.764 mm)
.
Valve Seat Bore
Diameter (Exhaust)
3-3
1.251 0-1.2520
(31.775-31.801 rnm)
