Technical description
The main RF-unit
The unit's output power is stable, highly precise and well integrated, containing
the following parameters:
The equipment is a high-tech, high-quality unit, having the latest available
techniques inside. The device is shown in the figure.
Technical data
Line voltage: AC 230/110 V 50-60Hz
Power input: ≈1600VA/7A
Output RF Voltage (50 Ω) range: 0-130V
Output power by RF generator: max
250W
Output useful power: max 150W
default - 60W
Nominal load is 50 Ω.
Tuning: The auto-matching unit (auto-tuner) always
tunes for a calibrated value, a standard 50Ω (fits the
impedance), so that the delivered output power is
calibrated.
Output carrier frequency: 13.56MHz
(quartz stabilised)
Output modulating frequency: 0-5 kHz,
(experimentally optimised)
Weight (including cables): 175 kg
Height: 1720mm
Electrical safety classification:
Class I, Type BF (according to IEC 60601-1)
