Onkyo HT-S5400 User Manual

29
En
■ Listening Modes
Listening Mode Description Input
Source
Speaker
Layout
Direct In this mode, audio from the input source is output without surround-sound
processing. The speaker configuration (presence of speakers) and speaker
distance settings are enabled, but much of the processing set via Home menu
is disabled. A/V Sync does not have effect on the analog audio. See
“Advanced Setup” for more details (➔ page 34).
A
S
D
F
G
H
ZXC
N
*2
Stereo Sound is output from the front left and right speakers and subwoofer.
A
S
D
F
G
H
ZXC
N
Mono Use this mode when watching an old movie with a mono soundtrack, or use
it with the foreign language soundtracks recorded in the left and right
channels of some movies. It can also be used with DVDs or other sources
containing multiplexed audio, such as karaoke DVDs.
Multichannel This mode is for use with PCM multichannel sources.
DXCN
Dolby Pro Logic IIx
*3
Dolby Pro Logic II
Dolby Pro Logic IIx expands any 2-channel source for 7.1-channel
playback. It provides a very natural and seamless surround-sound experience
that fully envelops the listener. As well as music and movies, video games
can also benefit from the dramatic spatial effects and vivid imaging. If
you’re not using any surround back speakers, Dolby Pro Logic II will be
used instead of Dolby Pro Logic IIx.
• Dolby PLIIx Movie
Use this mode with any stereo or Dolby Surround (Pro Logic) movie (e.g.,
TV, DVD, VHS).
• Dolby PLIIx Music
Use this mode with any stereo or Dolby Surround (Pro Logic) music source
(e.g., CD, radio, cassette, TV, VHS, DVD).
• Dolby PLIIx Game
Use this mode with video games, especially those that bear the Dolby Pro
Logic II logo.
SXCN
• Dolby PLIIx Movie, Dolby PLIIx Music
These modes use the Dolby Pro Logic IIx modes to expand 5.1-channel
sources for 7.1-channel playback.
DN
Dolby Pro Logic IIz
Height
Dolby Pro Logic IIz Height is designed to more effectively use existing
program material when height channel speaker outputs are present. Dolby
Pro Logic IIz Height can be used to upmix a variety of sources from movies
and music, but are particularly well-suited to upmix game content.
S
D
F
N
*4
Dolby EX These modes expand 5.1-channel sources for 6.1/7.1-channel playback.
They’re especially suited to Dolby EX soundtracks that include a matrix-
encoded surround back channel. The additional channel adds an extra
dimension and provides an enveloping surround sound experience, perfect
for rotating and fly-by sound effects.
D
H
N
*5
Di rec t
Stereo
Mono
Mu l t i ch
PL Mov i e
PL Mus i c
PL Game
PL x Mov i e
PL x Music
PL x Game
PL z He i gh t
Dolby EX
PL z He i gh t
Dolby D EX

Onkyo HT-S5400 Specifications

General

Disc types supported	No
Optical disc player type	-
Apple docking compatibility	iPhone, iPod
Audio decoders	Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio
RMS rated power	- W
Audio output channels	7.1 channels
Audio formats supported	AAC, FLAC, MP3, WMA
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
FM radio	Yes
AM band range	530 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Front speaker type	2-way
Front speaker impedance	6 Ω
Front speaker peak power	130 W
Front speaker frequency range	55 - 50000 Hz
Satellite speaker frequency range	80 - 20000 Hz
Subwoofer peak power	120 W
Subwoofer frequency range	25 - 150 Hz
Product color	Black
HDMI in	4
USB version	2.0
Audio (L/R) in	6
Composite video in	5
SCART ports quantity	0
Number of HDMI outputs	1
Component video (YPbPr/YCbCr) in	2
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	480 W
Package weight	34000 g

Weight and Dimensions

Main unit weight	9000 g
Subwoofer weight	10800 g
Center speaker weight	2400 g
Satellite speaker weight	1000 g
Main unit dimensions (WxDxH)	435 x 328 x 150 mm
Subwoofer dimensions (WxDxH)	317.5 x 398 x 463 mm
Front speaker dimensions (WxDxH)	1550 x 170 x 375.5 mm
Center speaker dimensions (WxDxH)	420 x 121 x 115 mm
Satellite speaker dimensions (WxDxH)	115 x 96 x 230 mm
