OnRobot VG10 - Typical Applications; Operating Conditions; Whats in the Box

Typical applications
• Pick and place
• Palletizing
• Machine tending
• Material handling
Operating conditions
Minimum
Typical
Maximum
Unit
Power supply
20.4
24
28.8
Volts
Current consumption
50
600
1500
mA
Operating temperature
0
32
-
-
50
122
°C
°F
Relative humidity (non-condensing)
0
-
95
%
Calculated MTBF (operating life)
30000
-
-
hours
What’s in the box?
Everything you need to get started with the VG10 is included:
• 1 x VG10 Industrial Robot Vacuum Gripper
• 1 x Easy Tool Changer
• 1 x 200 mm M8 tool cable
• 16 x Fittings for vacuum cups (pre-mounted)
• 16 x 30 mm vacuum cups (pre-mounted)
• 4 x 40 mm vacuum cups
• 4 x 15 mm vacuum cups
• 16 x Blind screws
• 4 x Torx T30 M6 bolts
• 1 x pin (rotation lock)
• Torx 30 key
• 3 mm Allen hex key
• User manual
• USB stick
- URCaps (PolyScope >= 3.3 support)
- User manual
