User Manual
or the Serial Console if you are using an external modem on the Console port or USB Modem if
you are using a USB modem on an ACM7000.
2. Specify the Probe Addresses of two sites (the Primary and Secondary) that the console server is
to ping to determine if Network / Network1 is operational
3. Select the System > Dial menu option and the port to be configured (Serial Console or Internal
Modem Port)
4. Select the Baud Rate and Flow Control that will communicate with the modem
5. Check the Enable Dial-Out Access box and enter the access details for the remote PPP server to
be called
Override DNS is available for PPP Devices such as modems. Override DNS allows the use of alternate
DNS servers from those provided by your ISP. For example, an alternative DNS may be required for
OpenDNS used for content filtering.
To enable Override DNS, check the Override returned DNS Servers box. Enter the IP of the DNS servers
into the spaces provided.
