Finally, open the re door and turn the screw positioned in the bottom left-hand corner clockwise, using the spanner provided.
To understand whether the insert is correctly attached to the base, connect the plug to the current socket and check that the
display switches on.
Assemble the pellet hopper support and insert it into the relevant coupling. N.B. if our pedestal is used, it is necessary to create
a slot in the chimney, which allows to control the level of pellets in the tank, thus preventing escape during lling.
Assembled pedestal
PARTS LIST
ELEMENT DESCRIPTION
1 Internal air inlet
2 Internal air outlet
3 rock wool insulation
4 smoke exhaust pipes
Insert on pedestal: installation area requirements
Opening
