Insert on existing chimney: installation area requirements
PARTS LIST
ELEMENT DESCRIPTION
1 Internal air inlet
2 Internal air outlet
3 Smoke exhaust Pipes
4 Smoke exhaust pipes
The gure below indicates an electric component present on the left side of the stove/insert:
Safety thermostat (manual reset), which starts to run if the smoke fan or exchanger should block (see Figure below on the
right).
Probe for internal control of the pellet tank, which operates if a given temperature is exceeded, automatically decreasing
the power of use, for greater safety.
Safety thermostat
