42
Model 72 User Manual - OPEX Corporation
TOP CUT OPTION
Figure 51: Top Cut Option screen
This job parameter is used to identify where the side cutter should be set. This
does not actually adjust the top cutter - it is used to inform the operator where
the recommended setting for the top cutter should be. It is the responsibility of
the operator to set the proper cut depth. The top cut amount can be adjusted
by moving the cursor with the right and left arrows and pressing Enter.
Print All Jobs or Individual Job Parameters
Job Information can be printed out for a single job or all jobs. The printout
includes the job name and all job parameters. The user must be logged in as a
supervisor to printout the report. The print choices are available from the
CHANGE JOB LIST screen.
Figure 52: Change Job List screen
Note: If you want to print information for a specific job, you will be presented
with an additional screen where you can choose the job.
TOP CUT OPTION
NO CUT (-----------------------) DEEP CUT
0.......1.......2.......3.......4.......
CHANGE JOB LIST
DELETE
SELECT
PRINT
ADD
CHANGE
SORT LIST
PRINT ALL
Selects an individual
job and prints
all parameters
associated with it
Prints the
entire list
of all jobs
To Next Page
