Model 72 User Manual - OPEX Corporation
Changing the Feed belts
The feeder belts are operator changeable. If the belts look worn, cracked, or
have become brittle, they will need to be replaced.
1 Carefully remove the cover from the feeder area by lifting it up and away
from the machine.
Figure 69: Front cover
2 Loosen the thumb screw on the feed guide, and push the guide away from
the belt assembly, as shown in Figure 70.
Feeder cover
