Opex AS3690 - Navigating the CertainScan Interface

2 Operating the System
August 2010 AS-Series Operator Manual 2-7
Navigating CertainScan
Use CertainScan to set up and process jobs on the AS-Series system. The
CertainScan interface consists of:
Title bar The title bar displays the name of the current operator and other pertinent
information. Click the AS-Series icon in the title bar to access the Windows functions
(Restore, Move, Size, Minimize, Maximize, Close), as well as the following menus:
-The Diagnostics menu contains the AS-Series system options. These options are
used by OPEX technicians to evaluate system performance.
-The Help menu accesses the About screen, which provides version information
for the CertainScan software.
Menu bar The vertical menu bar provides access to the main system functions.
Select a category from the menu bar and make selections from the main window or
the menu options bar.
Menu options The menu options provide subcategories for the selections in the
menu bar. The menu options bar will change based on the current menu bar
selection.
Main window View and adjust settings and parameters in the main window.
FIGURE 3: CertainScan interface
Menu bar
Main
Title bar
Menu options
window
