1 Introduction
August 2010 AS-Series Operator Manual 1-1
Overview
AS-Series systems are high-speed, color scanners that serves to reduce the costs and
time involved in processing documents. By scanning paper documents and
converting them into electronic files, the AS-Series scanner makes processing mail
and other paper documents as simple as pressing a few buttons. In just one step, the
system can identify, prepare, capture, orient, read, create an audit trail, and sort
your documents for you.
About the AS3690
The AS3690 system can process up to 5400 pieces of mail per hour. It can scan
unfolded legal size sheets, envelopes, checks and stubs, to business cards. It will
maintain transaction boundaries automatically, indicating the beginning and end of
a group of documents in a transaction.
Other features of the AS3690 include:
• PC controller, running Windows XP
• Color 17” LCD display with touch-screen controls
• Duplex scanner up to 300 DPI
• Selectable color drop-out
• Drop feeder with semi-automatic packet feeder
• Front and back audit trail printers
• Double-feed, length, skew, thickness, and envelope detection
• Image enhancement
• In-line recognition of barcodes, magnetic ink character recognition (MICR), optical
mark-sense recognition (OMR) and optical character recognition (OCR)
• Six output trays (four fully sortable bins, one thick mail bin, one reject bin)
• Paper size - Maximum 8.5” x 14” (Legal size). Minimum 2” x 3.5”
AS3690 specifications
Speed Up to 90 pages/minute
Paper & Envelope Specifications
Length: 3.5” to 14”
Height: 2” to 8.5“
Thickness: Up to 1/16”
Sound Level Below 72 dB
Duty Cycle 32,400 pages per day
Operator/Service Clearance 3' all around
Electrical
USA: 120 VAC, 3.5 AMPS, 60 Hz
EUROPE: 240 VAC, 2 AMPS, 50 Hz
