3 Operational Maintenance
August 2010 AS3690 Operator Manual 3-3
To adjust the carriage position, loosen the thumb screw, slide the carriage to a new
detented position on the shaft, and then retighten the thumb screw.
Loosen thumb screw to
move carriage along
detent shaft
