OPTICOM 764 - Page 40

Intersection Equipment Installation Instructions
40
Output Terminal Block & Signal Function
1
TB2 OUTPUT 1
Assignable for Preempt, TSP or Time Sync
2
TB2 OUTPUT 2
Assignable for Preempt, TSP or Time Sync
3
TB2 OUTPUT 3
Assignable for Preempt, TSP or Time Sync
4
TB2 OUTPUT 4
Assignable for Preempt, TSP or Time Sync
5
TB2 OUTPUT 5
Assignable for Preempt, TSP or Time Sync
6
TB2 OUTPUT 6
Assignable for Preempt, TSP or Time Sync
7
TB2 OUTPUT 7
Assignable for Preempt, TSP or Time Sync
8
TB2 OUTPUT 8
Assignable for Preempt, TSP or Time Sync
9
TB2 MSTRCTL (OUT 9)
Assignable for Preempt, TSP or Time Sync
10
TB2 MCEFREE (OUT10)
Assignable for Preempt, TSP or Time Sync
11
TB2 COORDISOL (OUT 11)
Assignable for Preempt, TSP or Time Sync
12
TB2 INTADV (OUT 12)
Assignable for Preempt, TSP or Time Sync
13
TB1 A CFRM
Channel A Confirmation light
14
TB1 B CFRM
Channel B Confirmation light
15
TB1 C CFRM
Channel C Confirmation light
16
TB1 D CFRM
Channel D Confirmation light
LOGIC
COMMON
TB1 or TB2
LOGIC COMMON (3 available)
Logic Common
Controller
24 VDC
TB 2 CTRL 24V
*To use a signal from the traffic controller to
activate the inhibit input, connect to Controller +24
VDC.
INHIBIT
TB 2 INHIBIT
* Connect to ground to disable all outputs
Table 9-1. Function of AIP outputs
