Intersection Equipment Installation Instructions
65
Appendix A1: Opticom Output Connection Worksheet (High & Low Priority)
Intersection Name: __________________________ Low Priority Active State ______________________
Radio Channel: _____________________________ Low Priority Output __________________________
HIGH Priority
Connect Phase Selector Output
To Controller Preempt Input Then, Program Controller to
Display Greens for:
Output _______________________ Input 1 Phases __ and __
Output _______________________ Input 2 Phases __ and __
Output _______________________ Input 3 Phases __ and __
Output _______________________ Input 4 Phases __ and __
Output _______________________ Input 5 Phases __ and __
Output _______________________ Input 6 Phases __ and __
Logic Common (gray/black) Logic Common
AIP Logic Common Logic Common
LOW Priority
Connect Phase Selector Output
To Controller Priority Input Then, Program Controller to
Display Greens for:
Output _______________________ Input 1 Phases __ and __
Output _______________________ Input 2 Phases __ and __
Output _______________________ Input 3 Phases __ and __
Output _______________________ Input 4 Phases __ and __
Output _______________________ Input 5 Phases __ and __
Output _______________________ Input 6 Phases __ and __
Logic Common (gray/black) Logic Common
AIP Logic Common Logic Common
