OPTICOM 764 - Error Listing and Codes; Set Range Functionality

Intersection Equipment Installation Instructions
56
13.2.2 Error listing
Er displays a list of active errors, if any exist.
• Press the SELECT button to display Er.
• Press the TEST button to display any active errors in the system.
• Press the SELECT button to display the next error code.
• Continue to press the SELECT button until all active errors have been displayed.
o When the last error is displayed, pressing Select re-displays the first error code.
• Pressing TEST exits to the main menu.
Error Code
Definition
Error Code
Definition
--
No Errors
EE
24V
E1
Data Bus Error
EF
Future use
E2
Address Bus Error
EG
GPS
E3
Internal RAM Error
Eh
Radio Module
E4
External RAM Error
EI
Future use
E5
External Flash Error
EJ
Future use
E6
Data Flash/File System
Ek
Future use
E7
RTC
EL
Future use
E8
Unknown Identity
En
Future use
E9
Invalid Application
Eo
Future use
EA
No Application
EP
Future use
Eb
Switch hardware
Eq
Future use
EC
Display Hardware
Et
Future use
Ed
Watchdog Reset
EU
Future use
Table 13-2 Error Code Listing
13.2.3 Set Range
Sr Resets the range setting timeout. This will allow the phase selector to respond to a range setting code
transmitted by a range setting IR emitter. After the time out period, the range code has no effect on
operation of the phase selector. This feature ensures that setting range via an emitter is available only to
authorized personnel who have access to the traffic cabinet.
Reset the Range Setting Timeout:
• With no emitters present, press the SELECT button until Sr is displayed.
• Hold the TEST button for 5 seconds.
• Sr will flash when the reset has occurred.
Sr is also used to set range with a non-range setting emitter.
Set the range:
• Place a powered IR emitter equipped vehicle at the point where you want detection to begin.
• Press the SELECT button until Sr is displayed.
• Hold the TEST switch until the Sr flashes and the corresponding call LED lights.
• A new range value will be applied to all classes on this channel.
o This will set range only for the current profile/time plan.
o This function only applies to Infrared operation.
