OPTICOM 764 - Appendix A: Opticom Output Connection Worksheet (High Priority only); Worksheet for High Priority Output Connections

Intersection Equipment Installation Instructions
64
Appendix A: Opticom Output Connection Worksheet (High Priority only)
Intersection Name: _______________________________________
Radio Channel: __________________________________________
Connect Phase Selector Output To Controller Preempt Input Then, Program Controller to
Display Greens for:
Output _________________________ Input 1 Phases ____ and ____
Output _________________________ Input 2 Phases ____ and ____
Output _________________________ Input 3 Phases ____ and ____
Output _________________________ Input 4 Phases ____ and ____
Output _________________________ Input 5 Phases ____ and ____
Output _________________________ Input 6 Phases ____ and ____
Logic Common (gray/black) Logic Common
AIP Logic Common Logic Common
