Oracle Database Appliance X6-2-HA

Install the Oracle Database Appliance X3-2/X4-2 DE2-24P Storage Shelf Into a Rack
84 Oracle Database Appliance Owner's Guide • March 2017
c.
Insert and loosely tighten one screw through the back of the rack and
into the back of the rails [4].
Callout Description
1 Location pegs
2 Rail flange and label
3 Front mounting screw
4 Rear mounting screw
■
If you have a threaded rack:
