Prepare the CMA for Installation
No. Description
3 Velcro straps (6)
4 Connector B
5 Connector C
6 Connector D
7 Slide rail latching bracket (used with connector D)
8 Rear slide bar
9 Flat cable covers (not used with SPARC T8-1)
10 Round cable covers
3.
Ensure that the correct cable covers for your server are installed on the CMA.
This server uses the round cable covers.
Note - The CMA ships with three, flat cable covers installed. Before installing the CMA, you
must replace the flat cable covers with the round cable covers. If the round cable covers are
already on the CMA, skip the next step.
4.
(If needed) Remove the flat cable covers and install the round cable covers.
To remove the flat cable covers and install the round cable covers, perform these steps for each
cable cover:
a.
Lift up on the cable cover handle (the handle is colored green) and open it
180 degrees to the horizontal position (panels 1 and 2).
Installing the Server 39
