ST 9100 - HARDWARE GUIDE
2 SPECIFICATIONS
2.1 Temperature
Parameter Value
Operating Temperature Range -20° to +75°C (-4°F to +167°F)
Storage Temperature Range -20° to +60°C (-4°F to +140°F)
2.1.1 Internal Backup Battery Temperature
Table 1 defines the internal backup battery's temperature specifications.
Table 1: Transceiver with Internal Backup Battery Temperature Specifications
Parameter Value
Charge Temperature Range 0°C to +45°C (32°F to +113°F)
Discharge Temperature Range -20°C to +75°C (-4°F to +167°F)
Storage Range
≤ 1 month
≤ 3 months
≤ 1 year
Ideal for long-term storage
-20°C to +45°C (-4°F to +113°F)
-20°C to +35°C (-4°F to +95°F)
0°C to +30°C (32°F to +86°F)
10°C to +25°C (60±25% R.H.), (50°F to +77°F)
2.2 Electrical
2.2.1 Input Range
CAUTION: An external 5 A slow blow fuse must be added in series with the external voltage wire (Table 3).
Parameter Value
Power Supply Voltage 9 to 32 V DC
2.2.2 Power Consumption
Typical values with a transceiver input voltage of 12 VDC.
Table 2: Transceiver Input Currents
Mode of
Operation
Condition 25°C
(77°F)
-40°C
(-40°F)
85°C
(185°F)
Unit
Sleep Externally powered 212 203 500.98 µA
Charger ON 297 N/A N/A mA
SatCom
Tx
Burst current 733.87 720.77 728.13 mA
T413, Version 0.04 BETA © ORBCOMM
®
Proprietary
16
