ST 9100 - HARDWARE GUIDE
Parameter Value
Rx Operating Frequency 1518-1559 MHz
Tx Operating Frequency 1626.5-1660.5 MHz, 1668-1675 MHz
2.6.3 Cellular Antenna
Parameter Value
Network Coverage Global: Cat 4 LTE (B1, B3, B5, B7, B8, B28), UMTS (850, 900, 1900, 2100), Quad-band GSM
Americas: Cat 1 LTE (B2, B4, B5, B12), UMTS (850, 900, 1900, 2100), Quad-band GSM
Frequency 700/824/960/1710/1880/2170/2600/2700 MHz
Impedance
50 Ω
VSWR 2.0:1
Gain 2.5 dB
Maximum EIRP 700-2700 MHz
2.6.3.1 Cellular Antenna Electrical
Frequency (MHz) Return Loss (dB) VSWR Efficiency (%) GAIN (dB)
700 -10.62 1.85 46.03 1.45
824 -22.27 1.16 36.48 0.6
960 -14.25 1.48 56.75 1.25
1710 -19.03 1.25 44.98 2.18
1880 -21.14 1.21 66.68 4.74
2170 -10.93 1.78 34.04 1.06
2600 -22.79 1.16 49.32 3.89
2700 -26.19 1.10 60.12 4.45
2.7 Satellite Transmitting Power
The maximum transmitting power (EIRP) for the IsatData Pro satellite is 7 dBW.
2.8 GNSS Module
The transceiver allows concurrent reception of up to three (3) GNSS channels.
The manufacturer's specifications are given in the table below.
Table 4: Multi-GNSS Specifications
Parameter GPS GLONASS BeiDou Galileo
Time to First Fix
Cold Start 29 s 30 s 34 s 45 s
Warn Start
2s 2 s
3 s 7 s
