ST 9100 - HARDWARE GUIDE
Parameter Condition Min. Typ. Max. Units
Output Data Rate (ODR) selectable via digital interface 12.5 - 1600
1
Hz
Sensitivity 2 g - 16384 - LSB/g
4 g - 8192 - LSB/g
8 g - 4096 - LSB/g
16 g - 2048 - LSB/g
Sensitivity Temperature Drift 3 V supply - ±0.02 - %/K
Zero-g Offset Ta = 25°C (77°F) - ±40 - mg
Zero-g Offset Temperature Drift 3 V supply - ±1 - mg/K
Wake up Time from low power or suspended modes - 0.8 - ms
Start up Time power on reset - 3.2 3.8 ms
2.13 Cellular Module - LTE
2.13.1 Transceivers Operating in the Americas
Transceivers (p/n ST9100-D01), operating in North or South America, have the following characteristics.
Type u-blox Toby R200 series
LTE Module LTE bands: 2, 4, 5, 12
UMTS bands: 850, 900, 1900, 2100 MHz
GSM 850/900/1800/1900 MHz
Output Power LTE power Class 3 (23dBm)
UMTS/HSDPA/HSUPA power Class 3 (24dBm)
GSM/GPRS Power Class:
*Class 4 (33 dBm) for GSM/E-GSM band
*Class 1 (30 dBm) for DCSPCS band
EDGE(8-PSK) Power Class:
*Class E2 (27 dBm) for GSM/E-GSM band
*Class E2 (26 dBm) for DCS/PCS band
Input Power Peak currents of 1.5 A typical, 1.9 A maximum. Module supply peak current consumption: peak of
current consumption through the VCC pins during a GSM 1-slot Tx burst at maximum Tx power,
with a matched antenna
Data Transfer LTE Category 1: up to 10.3Mb/s DL, 5.2 Mb/s UL
HSDPA category 8: up to 7.2 Mb/s DL, HSUPA category 6: up to 5.76 Mb/s UL
GPRS multi-slot class 33, CS1-CS4, up to 107 kb/s DL, up to 85.6 kb/s UL
EDGE multi-slot class 33, MCS1-MCS9, up to 296 kb/s DL, up to 236.8 kb/s UL
Antenna Detect Output DC current pulse: 9 µA typical
Output DC current pulse time length: typical 330 µs
2.13.2 Transceivers Operating Outside of the Americas
Transceivers (p/n ST9100-C01), operating outside of North or South America, have the following characteristics.
1
The software supports a maximum ODR of 400 Hz.
T413, Version 0.04 BETA © ORBCOMM
®
Proprietary
31
