Version 2.1 23
ACCESS TO PARTS
2 ACCESS TO PARTS
2.1 Open the cover assembly
1. Loosen the four bolts (A) and the washers
(B) and (C).
2. Open the cover assembly.
2.2 Close the cover assembly
1. Close the cover assembly.
2. Tighten the four bolts (A) and the washers
(B) and (C) with a torque of minimum 2.5
Nm and maximum 3.5 Nm.
3. On the control panel, turn the mains
power switch to the ON position.
4. Switch on the (mains) power supply.
5. Do a function test.
WARNING
Make sure that the equipment is de-energized:
1 On the control panel, turn the mains power switch to the OFF position.
2 Switch off the mains power supply.
