5.1.14 Aeronautical obstruction light L85EX-R-DC-200
Explosion proof LED aeronautical obstruction light.
/i
Table 53 Standards and certification
/i
Table 54 Performance characteristics
/i
Table 55 Electrical characteristics
/i
Table 56 Physical characteristics
Standards/Certification Complies with CAA-UK CAP 437;Offshore helicopter landing
areas - Guidance on standards, 7th edition Feb 2013, chapter
4,paragraph 4.4
Cenelec EN 60079-0, EN 60079-7 and EN 60079-18
SIRA 12ATEX3066 X; ATEX II 2G Ex e mb IIC T4 Gb
IEC 60079-0, IEC 60079-7 and IEC 60079-18
IECEx SIR 12.0026 ; Ex e mb IIC T4 Gb
NCC 12.1223; Ex e mb IIC T4 Gb
LED Steady burning; red
Intensity 200cd minimum (between 5° - 8°) and
50cd minimum (between 0° - 15°)
Horizontal beam coverage 360º
Vertical beam profile: As per CAP168 Chapter 4 and Appendix 6,Table 6A.1, Group B
Light source LED (100,000 hours average life)
Colour chromaticity Within the boundaries as specified by ICAO
Operating voltage 20-30 Vdc
Power consumption Approx. 7,5 W
Connection details M4; two M25x1.5 cable entries
Dimensions (L x W x H) 161 x 161 x 111 mm
Weight 3.6 kg
Degree of protection IP66
Operating temperature range
ATEX/IECEx
-40 ºC to +55 ºC
Operating temperature range
Inmetro
-50 ºC to +45 ºC
