5.1.4 Aeronautical obstruction light L85EX-R-AC-32
Explosion proof LED aeronautical obstruction light.
/i
Table 13 Standards and certification
/i
Table 14 Performance characteristics
/i
Table 15 Electrical characteristics
/i
Table 16 Physical characteristics
Standards/Certification Certified to ICAO Annex 14, volume l; : Aerodrome design and
operation, 6th Edition, 2013, chapter 6.3.2 - Type B low intensity
obstacle light
Certified to IMO standard, MODU code 2009 (Edition 2010) , chap-
ter 13.5.24
Cenelec EN 60079-0, EN 60079-7 and EN 60079-18
SIRA 12ATEX3066 X; ATEX II 2G Ex e mb IIC T4 Gb
IEC 60079-0, IEC 60079-7 and IEC 60079-18
IECEx SIR 12.0026 X; Ex e mb IIC T4 Gb
NCC 12.1223; Ex e mb IIC T4 Gb
LED Steady burning; red
Intensity Minimum 32 cd
Horizontal beam coverage 360º
Vertical beam profile As per ICAO
Colour chromaticity Within the boundaries as specified by ICAO
Light source LED (100,000 hours average life)
Operating voltage 100-254 Vac; 50-60 Hz
Power consumption Approx. 5.5 W (7 VA)
Connection details M4; two M25x1.5 cable entries
Earth connection Internal M4 and external M6
Dimensions (L x W x H) 161 x 161 x 111 mm
Weight 3.6 kg
Degree of protection IP66
Operating temperature range
ATEX/IECEx
-40 ºC to +60 ºC
Operating temperature range
Inmetro
-50 ºC to +45 ºC
