5.1.3 Aeronautical obstruction light L85EX-R-AC-10
Explosion proof LED aeronautical obstruction light.
/i
Table 9 Standards and certification
/i
Table 10 Performance characteristics
/i
Table 11 Electrical characteristics
/i
Standards/Certification Certified to ICAO Annex 14, volume l; 5th Edition, November2009,
chapter 6.3.2 – Type A low intensity obstacle light
Certified to IMO standard MODU code; 2009 (Edition 2010),chap-
ter 13.5.24
Certified to CAA-UK CAP 437;Offshore helicopter landing areas -
Guidance on standards,7TH edition, chapter 4,paragraph 4.3
Complies with CAA-UK CAP 168; July 2010, chapter 4,
paragraph12.8.1a, 12.10.2, 12.11.3 and table 6A.1.11 – Low inten-
sity aeronautical obstruction light -Group A
Certified to Mining regulations of The Netherlands 2003, - Article
5.5
Certified to German "General Administrative Regulation for the
marking and lighting of obstacles to air avigation" Low Intensity
Type A / Hindernisfeuer
Cenelec EN 60079-0, EN 60079-7 and EN 60079-18
SIRA 12ATEX3066 X; ATEX II 2G Ex e mb IIC T4 Gb
IEC 60079-0, IEC 60079-7 and IEC 60079-18
IECEx SIR 12.0026; Ex e mb IIC T4 Gb
NCC 12.1223; Ex e mb IIC T4 Gb
LED Steady burning; red
Intensity Minimum 10 cd
Horizontal beam coverage 360º
Vertical beam profile Visible from any point above the horizon
Colour chromaticity Within the boundaries as specified by ICAO
Light source LED (100,000 hours average life)
Operating voltage 100-254 Vac; 50-60 Hz
Power consumption Approx. 2.5 W (4 VA)
Connection details M4; two M25x1.5 cable entries
Earth connection Internal M4 and external M6
