ORGA L85EX User Manual

54 Version 2.1
A.2 Spare parts
Depending on the platform and the local regulations, order the relevant parts. All parts that
are available are listed below.
/i
Note
Depending on the platform and the local regulations, order the relevant parts.
All parts that are available are listed below.
Name Part number
Control unit for L85EX-R-AC-50/200: LPS8511-R0900
Includes O-ring and adhesive. Always apply before closing the lamp.
071819
Control unit for L85EX-R-AC-32 (LPS8511-R0910)
Includes O-ring and adhesive. Always apply before closing the lamp.
071820
Control unit for L85EX-G/B-AC (LPS8511-R0920)
Includes O-ring and adhesive. Always apply before closing the lamp.
071821
Control unit for L85EX-R-AC-10 & L85EX-Y-AC (LPS8511-R0930)
Includes O-ring and adhesive. Always apply before closing the lamp.
071822
Control unit for L85EX-R-DC50/200 (LPS2411-R1200)
Includes O-ring and adhesive. Always apply before closing the lamp.
074998
Control unit for L85EX-R-DC-32 (LPS2411-R1210)
Includes O-ring and adhesive. Always apply before closing the lamp.
075000
Control unit for L85EX-G-DC & L85EX-B-DC (LPS2411-R1220)
Includes O-ring and adhesive. Always apply before closing the lamp.
075002
Control unit for L85EX-R-DC-10 & L85EX-Y-DC (LPS2411-R1230)
Includes O-ring and adhesive. Always apply before closing the lamp.
075004
Cover assembly for L85EX-G-AC (green LEDs) 071823
Cover assembly for L85EX-R-AC-10/32 (red LEDs) 071824
Cover assembly for L85EX-R-AC-50 (red LEDs) 071825
Cover assembly for L85EX-R-AC-200 (red LEDs) 071826
Cover assembly for L85EX-B-AC (blue LEDs) 071827
Cover assembly for L85EX-Y-AC (yellow LEDs) 071828
O-ring adhesive (Soudal Silirub 2 (310ml)) 074522
Dome set
Includes dome, clamping ring (+4 bolt sets), sealing ring
071830
O-ring set
Includes adhesive.
074520
Earth bolt set
Includes earth mounting bolt, spring lock washer, washer, earthing tag
017129
