TECHNICAL DATA
5.1.12 Aeronautical obstruction light L85EX-R-DC-32
Explosion proof LED aeronautical obstruction light.
/i
Table 45 Standards and certification
/i
Table 46 Performance characteristics
/i
Table 47 Electrical characteristics
/i
Table 48 Physical characteristics
Standards/Certification operations, 6th Edition, 2013, chapter 6.3.2 - Type B low intensity
obstacle light
Certified to IMO standard, MODU code; 2009 (Edition 2010),
chapter 13.5.24
Cenelec EN 60079-0, EN 60079-7 and EN 60079-18
SIRA 12ATEX3066 ; ATEX II 2G Ex e mb IIC T4 Gb
IEC 60079-0, IEC 60079-7 and IEC 60079-18
IECEx SIR 12.0026 X; Ex e mb IIC T4 Gb
NCC 12.1223; Ex e mb IIC T4 Gb
LED Steady burning; red
Intensity 32cd minimum (all angles above horizon)
Horizontal beam coverage 360º
Vertical beam profile: As per ICAO
Light source LED (100,000 hours average life)
Colour chromaticity Within the boundaries as specified by ICAO
Operating voltage 20 - 30 Vdc
Power consumption 5 W
Connection details M4; two M25x1.5 cable entries
Earth connection Internal M4 and external M6
Dimensions (L x W x H) 161 x 161 x 111 mm
Weight 3.6 kg
Degree of protection IP66
Operating temperature range
ATEX/IECEx
-40 ºC to +60 ºC
Operating temperature range
Inmetro
-50 ºC to +45 ºC
