Version 2.1 43
TECHNICAL DATA
5.1.11 Aeronautical obstruction light L85EX-R-DC-10
Explosion proof LED aeronautical obstruction light.
/i
Table 41 Standards and certification
/i
Table 42 Performance characteristics
/i
Table 43 Electrical characteristics
/i
Standards/Certification Certified to ICAO Annex 14,volume l; Aerodrome design andoper-
ations, 6th Edition, 2013, chapter 6.3.2 - Type A low intensity
obstacle light
Certified to IMO standard MODU code; 2009 (Edition 2010),chap-
ter 13.5.24
Certified to CAA-UK CAP 437;Offshore helicopter landingareas -
Guidance on standards, 7th edition, chapter 4,paragraph 4.3
Complies with CAA-UK CAP 168;July 2010, chapter 4,
paragraph12.8.1a, 12.10.2, 12.11.3 and table 6A.1.11 – Low inten-
sityaeronautical obstruction light Group A
Certified to Mining regulations of the Netherlands; 2002,article 5.5
Certified to German "General Administrative Regulation for the
marking and lighting of obstacles to air avigation" Low Intensity
Type A / Hindernisfeuer
Cenelec EN 60079-0, EN 60079-7 and EN 60079-18
SIRA 12ATEX3066; ATEX II 2G Ex e mb IIC T4 Gb
IEC 60079-0, IEC 60079-7 and IEC 60079-18
IECEx SIR 12.0026 X; Ex e mb IIC T4 Gb
NCC 12.1223; Ex e mb IIC T4 Gb
LED Steady burning; red
Intensity 10 cd
Horizontal beam coverage 360º
Vertical beam profile: Visible from any point above the horizon
Light source LED (100,000 hours average life)
Colour chromaticity Within the boundaries as specified by ICAO
Operating voltage 20 - 30 Vdc
Power consumption 2 W
Connection details M4; two M25x1.5 cable entries
Earth connection Internal M4 and external M6
