OSRAM BT Control | Applications and settings
28
5.1.2.3 Out-of-the-box features (no app for configuration needed!)
Attention: For this application, the out-of-the-box features are not sufficient.
Additional configuration via the OSRAM BT Config App is required (see chapter 5.1.2.3 ff.)!
5.1.2.4 Configuration via the OSRAM BT Config App
The controller can be configured via smartphone with the OSRAM BT Config App.
The BT Config App configuration is mandatory for this application!
The grouping feature needs to be activated, the HCL function needs to be deactivated and the two pushbuttons need to
be configured as well.
Important note:
After powering up the controller, it can be configured with the BT Config App for two hours only (as long as no admin
password is stored). After the two-hour delay time has expired, connecting to the controller with the BT Config App is
blocked. The timer can be reset by power-cycling the controller. When an admin password is set, the access to the con-
troller will no longer expire.
DALI LS/PD LI
DA
DA
L
N
Pe
DALI LED driver
(direct light)
L
N
Pe
DA
DA
TW control
with second
pushbutton
DALI ECO BT RTC
L
N
PB
PB
DA
DA
DALI LED driver
(indirect light)
L
N
Pe
DA
DA
820 Ω,
5 %,
0.25 W
